ER2M 010S

KITO ER2M: ER2 electric chain hoist on MR2 motor trolley (the brochure pictures an "ER2M 100 S", p.50). Hoist:, body size D. KITO "Hoists Main Brochure" (EN, kito.net) technical data p.53 lists this capacity as type ER2-010IS: 1000 kg, lifting motor 1.8 kW at 40/20 % ED, lifting speed at 50 Hz 8.2 high / 1.4 low (standard) or 8.2 / 0.7 (adjustable), load chain 7.7 mm, 1 chain fall(s), FEM/ISO 2m / ISO M5, headroom C 430 mm, weight 52 kg plus 1.33 kg per extra metre of lift. The brochure labels its ER2 photos in the short form "ER2 100 S" (p.50), the same pattern as this record's name; the table code is ER2-010IS. Features p.50: 380-440 V / 50 Hz, 24 V control, frequency inverter for dual speed, carbon friction clutch overload limiter, operating-hours / load-cycle counter, thermal motor protection. The standard-setting row prints the high speed as "82"; the adjustable row of the same type reads 8.2, which is the value used. A slower ER2-010IL (0.9 kW, 4.2 m/min, 45 kg) also exists. Industrial hoist; KITO states no entertainment (D8/D8+/C1) rating. Trolley: MR2 1,000 technical data p.85: single speed (S) 20.0 m/min at 40 % ED, or dual (IS) 24.0/4.0-2.4 m/min at 27/13 % ED; flange width 58-163 mm; minimum curve radius 800 mm. Trolley mass is not stated, so the weight given is the hoist alone.
